Product Model
TSXDEZ12D2
Selling Points
- 1High reliability and durability for long-lasting performance.
- 2Compact design for easy installation in tight spaces.
- 3Advanced thermal management to prevent overheating.
- 4Compliant with international safety standards for secure operation.
- 5Versatile configurations to meet diverse industrial needs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon TSX Micro automation platform | Product or Component Type | Discrete input module |
Discrete input number | 12 screw terminal block | Discrete input voltage | 24 V DC positive or negative<br />19...30 V |
Discrete input current | 9 mA | Input voltage limits | >= 11 V at state 1<br />< 5 V at state 0 |
Current state 0 guaranteed | <= 1.5 mA | Current state 1 guaranteed | >= 2.5 mA |
input impedance | 2.4 Ohm | Response time | 0.1...7.5 ms at state 0 to state 1<br />0.1...7.5 ms at state 1 to state 0 |
Standards | IEC 1131-2 Type 1 | Input compatibility | 2/3-wire proximity sensors PNP/NPN |
Discrete input type | Resistive | Current consumption | 123 mA positive<br />107 mA negative |
Isolation voltage | 1500 V AC 1 s | Net Weight | 0.51 lb(US) (0.23 kg) |
Specifications may be subject to change without notice
