Product Model
TSXDSY64T2KC
Selling Points
- 1High-capacity power supply with 64A output.
- 2Compact design for easy integration in various systems.
- 3Wide range of input voltage options for flexibility.
- 4Enhanced reliability with robust construction and quality components.
- 5Compliant with international safety standards for secure operation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon Premium Automation platform | Product or Component Type | Discrete output module |
Discrete output number | 64 | Discrete output type | Solid state protected |
Discrete output voltage | 24 V DC positive EN/IEC 61131-2 19...30 V | Current per channel | 0.1 A |
Maximum current per module | 5 A | Maximum leakage current | 0.1 mA 30 V |
Maximum tungsten load | 1.2 W | [Ures] residual voltage | 1.5 V |
Response time | 1.2 ms | Paralleling of outputs | Yes : 3 maximum |
Output overvoltage protection | By transil diode | Reverse polarity protection | Reverse mounted diode |
Output overload protection | Automatic trip | Short-circuit protection | Automatic trip |
Minimum load impedance | 220 W at state 1 | isalotion resistance | > 10 MOhm 500 V |
Power dissipation | (2.4 W + 0.1 W x No of outputs) | Product Compatibility | Dial and Power |
marking | CE | Electrical connection | 4 connectors HE-10 |
Current consumption | 155 mA 5 V DC | Module format | Standard |
Net Weight | 0.79 lb(US) (0.36 kg) | Dielectric strength | 1500 V 50/60 Hz 60 s |
Standards | 73/23/EEC<br />89/336/EEC<br />CSA C22.2 No 142<br />92/31/EEC<br />CSA C22.2 No 213 Class I Division 2 Group A<br />UL 508<br />CSA C22.2 No 213 Class I Division 2 Group D<br />IEC 61131-2<br />93/68/EEC<br />CSA C22.2 No 213 Class I Division 2 Group B<br />CSA C22.2 No 213 Class I Division 2 Group C | Product Certifications | DNV<br />BV<br />GL<br />LR<br />RINA<br />RMRS<br />ABS |
Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) | Ambient Air Temperature for Storage | -13…158 °F (-25…70 °C) |
Relative Humidity | 10…95 % without condensation for operation<br />5…95 % without condensation for storage | Operating altitude | 0...6561.68 ft (0...2000 m) |
Protective treatment | TC<br />Conformal coating Humiseal 1A33 | IP Degree of Protection | IP20 |
Pollution degree | 2 |
Specifications may be subject to change without notice
