Product Model
TSXP57353LAMC
Selling Points
- 1High-performance 3-phase power supply designed for critical applications.
- 2Compact and lightweight design for easy integration into systems.
- 3Robust construction with enhanced thermal management for extended lifespan.
- 4Meets or exceeds international safety standards for reliable operation.
- 5Compatible with a wide range of industrial control systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon Premium Automation platform | Product or Component Type | Single-format PL7 processor |
Software Designation | PL7 Junior/Pro | Number of racks | 16 4/6/8 slots<br />8 12 slots |
Number of slots | 128<br />96<br />64 | Discrete I/O processor capacity | 1024 I/O |
Analogue I/O processor capacity | 128 I/O | Number of application specific channel | 32 |
Number of process control channel | 15 up to 45 simple loops | Integrated connection type | Fipio manager (127 agents) SUB-D 9<br />Non isolated serial link 2 female mini DIN19.2/115 kbit/s) |
Communication module processor capacity | 2 fieldbus modules (1 if CANopen used)<br />8 AS-Interface bus modules<br />1 CANopen<br />3 network module | Memory description | Internal RAM (with PCMCIA card) 96 Kwords data<br />Internal RAM (without PCMCIA card) 80 Kwords program and data<br />PCMCIA card 2688 Kwords additional data storage<br />PCMCIA card 384 Kwords program |
Maximum size of object areas | 16384 %Mi located internal bits<br />30.5 %MWi internal words located internal data<br />32 %KWi constant words located internal data | Application structure | 64 event tasks<br />1 fast task<br />1 master task |
Execution time per instruction | 0.19 µs Boolean without PCMCIA card<br />0.21 µs Boolean with PCMCIA card<br />0.25 µs word or fixed-point arithmetic without PCMCIA card<br />0.42 µs word or fixed-point arithmetic with PCMCIA card<br />2.6 µs floating points with PCMCIA card<br />2.6 µs floating points without PCMCIA card | Number of instructions per ms | 2.5 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card<br />3.57 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card<br />3.7 Kinst/ms 100 % Boolean with PCMCIA card<br />4.76 Kinst/ms 100 % Boolean without PCMCIA card |
System overhead | 0.35 ms fast task<br />1 ms master task | marking | CE |
Local signalling | for processor running (RUN) 1 LED (green)<br /> for activity on Fipio bus (FIP) 1 LED (red)<br /> for I/O module or configuration fault (I/O) 1 LED (red)<br /> for processor or system fault (ERR) 1 LED (red)<br /> for activity on the terminal port (TER) 1 LED (yellow) | Current consumption | 1650 mA 5 V DC |
Module format | Standard | Net Weight | 0.93 lb(US) (0.42 kg) |
Standards | 93/68/EEC<br />CSA C22.2 No 213 Class I Division 2 Group A<br />CSA C22.2 No 213 Class I Division 2 Group B<br />UL 508<br />89/336/EEC<br />73/23/EEC<br />CSA C22.2 No 142<br />CSA C22.2 No 213 Class I Division 2 Group C<br />92/31/EEC<br />CSA C22.2 No 213 Class I Division 2 Group D<br />IEC 61131-2 | Product Certifications | BV<br />ABS<br />RINA<br />GL<br />DNV<br />RMRS<br />LR |
Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) | Ambient Air Temperature for Storage | -13…158 °F (-25…70 °C) |
Relative Humidity | 10…95 % without condensation for operation<br />5…95 % without condensation for storage | Operating altitude | 0...6561.68 ft (0...2000 m) |
Protective treatment | Conformal coating Humiseal 1A33<br />TC | IP Degree of Protection | IP20 |
Pollution degree | 2 |
Specifications may be subject to change without notice
