Product Model
TSXSAY1000
Selling Points
- 1Advanced Power Protection: Safeguards your equipment from power surges, outages, and voltage fluctuations.
- 2High Capacity: Offers up to 1000VA, ensuring continuous operation during extended power outages.
- 3Efficient Operation: Features low energy consumption and high efficiency, reducing your overall energy costs.
- 4Compact Design: Sleek and space-saving design ideal for small to medium-sized businesses and data centers.
- 5Enhanced Reliability: Built with high-quality components and rigorous testing for maximum uptime and minimal downtime.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Modicon Premium Automation platform | Product or Component Type | AS-Interface master module |
Range Compatibility | AS-Interface cabling system | Actuator sensor interface profile [AS-i] | M2E |
AS-i version | V2 | Addressing | Standard and extended |
Number of server device(s) | 31, extended<br />31, standard | Type of connectable interfaces | Analog I/Os, standard<br />Discrete I/Os (4I/3O), extended<br />Discrete I/Os (4I/4O), standard<br />Safety interfaces, standard |
Electrical connection | 1 male connector SUB-D, 3 ways | Supply | Via power supply integrated into the host platform of the module |
Current consumption | 450 mA 5 V DC | Local signalling | Display unit |
Number of modules per base controller | 1 TSX570.<br />1 TSX57C.<br />2 TSX571.<br />4 TSX572.<br />8 TSX573.<br />8 TSX574.<br />8 TSX575.<br />8 TSX576. | Net Weight | 0.75 lb(US) (0.34 kg) |
Standards | IEC 60068-2-27, Ea tests<br />IEC 60068-2-6, Fc tests | Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
Ambient Air Temperature for Storage | -13…158 °F (-25…70 °C) | IP Degree of Protection | IP20 |
Specifications may be subject to change without notice
