schneiderPLC/PAC and Controllers
Product Model

TSXWMY100

Manufacturer

schneider

Category

PLC/PAC and Controllers

Product ID

34791

In Stock
Last updated: 2025/4/18
View Specifications
schneider TSXWMY100

Selling Points

  • 1High-performance power supply designed for critical applications.
  • 2Compact and lightweight, ideal for space-constrained environments.
  • 3Wide input voltage range (100-240V) for global compatibility.
  • 4Built-in protection features including overvoltage, undervoltage, and overcurrent protection.
  • 5Meets or exceeds industry standards for reliability and safety.
Product Details
TSXWMY100
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Range of Product
Modicon Premium Automation platform
Product or Component Type
Ethernet TCP/IP module
Physical interface
RJ45 - 10BASE-T/100BASE-TX 1 twisted pair
Transmission rate
10/100 Mbit/s
Communication service
Modbus TCP messaging<br />SMTP e-mail notification<br />SNMP agent<br />SOAP XML Web (client/server)<br />Uni-TE messaging
Supply
Via the power supply of the rack
Local signalling
for collision detection (COL) 1 LED (red)<br /> for configuration status (STS) 1 LED (amber)<br /> for Ethernet network status (RUN) 1 LED (green)<br /> for Ethernet port fault (ERR) 1 LED (red)<br /> for transmission activity (TX) 1 LED (amber)<br /> for reception activity (RX) 1 LED (amber)
communication port protocol
Modbus TCP<br />Uni-Telway
Maximum number of connections
64
Web server
Transparent ready class D10
web feature
FactoryCast HMI active<br />Data Editor (via PC terminal)<br />Rack viewer<br />FactoryCast configurable
Memory description
User web page size 8 MB
marking
CE
Product compatibility
PL7 Pro<br />Unity Pro
Current consumption
360 mA 5 V DC
Module format
Standard
Net Weight
0.75 lb(US) (0.34 kg)
Standards
CSA 1010-1<br />FM Class 1 Division 2 group A<br />UL 508<br />FM Class 1 Division 2 group B<br />FM Class 1 Division 2 group D<br />EN 61131-2<br />FM Class 1 Division 2 group C
IP Degree of Protection
IP20
Ambient Air Temperature for Operation
32…140 °F (0…60 °C)
Relative humidity
10…95 % 140 °F (60 °C) without condensation

Specifications may be subject to change without notice
