schneider XB4BVBM1GEX

Selling Points

  • 1High reliability and durability for demanding industrial environments.
  • 2Compact design with minimal footprint for space-saving installations.
  • 3Wide input voltage range (36-72V DC) for flexibility in various applications.
  • 4High efficiency (up to 95%) to reduce energy consumption and heat generation.
  • 5Built-in protection features including overvoltage, undervoltage, and short-circuit protection.
Product Details
XB4BVBM1GEX
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Range of Product
Harmony XB4
Product or Component Type
Complete pilot light
Device short name
XB4
Bezel material
Chromium plated metal
Fixing collar material
Zamak
Mounting diameter
0.9 in (22 mm)
Sale per indivisible quantity
1
Dust zone
Zone 21 - 22
Gas zone
Zone 1 - 2
Operator additional information
With plain lens
Width
1.8 in (46.2 mm)
Height
1.2 in (30 mm)
Depth
2.7 in (69 mm)
Net Weight
0.183 lb(US) (0.083 kg)
Device mounting
Fixing hole 0.9 in (22.5 mm) +/- 0.2 mm IEC 60947-1
Fixing center
>= 30 x 40 mm support panel) 0.04…0.2 in (1…6 mm)
Embedding Depth
2.3 in (58 mm)
marking
II 2 GD<br />Ex eb mb IIC Gb<br />Ex tb IIIC Db
Shape of signaling unit head
Round
cap/operator or lens colour
White
Connections - terminals
Screw clamp terminals, 2 x 1.5 mm² with cable end IEC 60947-1<br />Screw clamp terminals, 1 x 2.5 mm² without cable end IEC 60947-1
Tightening torque
7.08…10.6 lbf.in (0.8…1.2 N.m) IEC 60947-1
Signalling type
Steady
Light source
Integral LED
Light source colour
White
[Us] Rated Supply Voltage
24...254 V AC/DC
Service life
100000 h
Protective treatment
TH
Ambient Air Temperature for Storage
-40…158 °F (-40…70 °C)
Ambient Air Temperature for Operation
-4…167 °F (-20…75 °C)
Overvoltage category
I IEC 60536
IP degree of protection
IP65 IEC 60529
Standards
IEC 60079-0:2009<br />IEC 60079-7:2009<br />EN/IEC 60079-18:2009<br />IEC 60079-31:2009<br />UL 60079-0<br />UL 60079-18<br />UL 60079-31<br />ANSI/ISA 12.12.01<br />CSA C22.2 No 213
Product Certifications
INERIS 04ATEX9003U

Specifications may be subject to change without notice
