Product Model
XBKP62230G30E
Selling Points
- 1High Accuracy Counting: Bi-directional counting up to 2500 Hz and uni-directional counting up to 5000 Hz.
- 2LED Display: 6-digit LED display for clear and precise readings.
- 3Automatic Reset: Automatic reset functionality for efficient operation.
- 4Versatile Applications: Suitable for tachometer, preselection, batch counter, and chronometer applications.
- 5Compact Design: Flush-mounted design with dimensions of 48 x 48 mm.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Range of Product | Zelio Count | Product or Component Type | Multifunctional counter |
Additional information | Chronometer<br />Tachometer<br />Preselection counter<br />Batch counter | Display Type | LED |
Size | 48 x 48 mm | Display digits | 6 |
Counting frequency | bi-directional counting 2500 Hz<br /> uni-directional counting 5000 Hz | Reset | Electrical reset<br />Manual<br />Automatic reset |
Counting capacity | -99999...999999 | Technology Type | Electronic |
[Us] Rated Supply Voltage | 24 V DC Us +/- 10 % | Current consumption | 150 mA 24 V DC |
Output type | Relay changeover 5 ms 5...250 V AC, 0.01…1 A<br />Relay changeover 5 ms 5...30 V DC, 0.01…1 A<br />Transistor PNP 12...24 V DC, 0.01 A | Preset number | 2 |
Counting mode | Counting direction inputs 5 kOhm)<br />Differential inputs 5 kOhm)<br />Single counter input 5 kOhm)<br />Single counter with phase discriminator 5 kOhm)<br />Summing inputs 5 kOhm) | Time range | 0...99 999.9 mn<br />0...99 h 59 mn 59 s<br />0...99 999.9 s<br />0...99 999.9 h |
Input type | Contact | Minimum pulse duration | 0.0001 s 5000 Hz<br />0.017 s 30 Hz |
Mounting Mode | Flush-mounted | Mounting Support | Panel mounting |
Fixing Mode | By self-locking clamp with setscrews | Connections - terminals | Screw terminal block |
Discrete input type | NPN or PNP | Display colour | Red |
Height | 1.9 in (48 mm) | Number of outputs | 3 |
Net Weight | 0.33 lb(US) (0.15 kg) | Width | 1.9 in (48 mm) |
CAD overall width | 1.9 in (48 mm) | CAD overall height | 1.9 in (48 mm) |
CAD overall depth | 4.02 in (102 mm) | Standards | EN 50082-2<br />EN 61010<br />EN 50081-2 |
Product Certifications | cURus | IP degree of protection | IP65IEC 60529 |
Ambient Air Temperature for Operation | 32…122 °F (0…50 °C) | Ambient Air Temperature for Storage | -4…158 °F (-20…70 °C) |
Vibration resistance | 1 gn 10…150 Hz)IEC 60068-2-6 | Shock resistance | 10 gn 18 ms IEC 60068-2-27 |
Electrical shock protection class | Class II IEC 60536 |
Specifications may be subject to change without notice
