schneider XBTZ9732

Selling Points

  • 1Connects Magelis XBT terminals to Allen-Bradley Micro-logix PLCs.
  • 2Equipped with one 8-way male mini DIN connector and one 25-way connector.
  • 3Compatible with all Magelis XBTN/R except XBT N200/N400 and XBT R400.
  • 4Supports RS232 protocol for reliable communication.
  • 5Green Premium product with sustainability features.
Product Details
XBTZ9732
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Range of Product
Harmony XBT
accessory / separate part category
Connection accessories
accessory / separate part type
Connecting cable
Accessory / separate part designation
Direct connection cable
Accessory / separate part destination
XBT terminal
Cable length
8.2 ft (2.5 m)
Product Compatibility
XBTR411<br />XBTN410<br />XBTNU400<br />XBTN401<br />XBTR410
Range Compatibility
Allen-Bradley SLC5
Electrical connection
1 connector Micro-logix 1000
communication port protocol
DH485
Physical interface
RS232
Net Weight
0.46 lb(US) (0.21 kg)

Specifications may be subject to change without notice
