schneiderPushbuttons, Switches, Pilot Lights, Control Stations and Joysticks
Product Model

ZB6EM6B

Manufacturer

schneider

Category

Pushbuttons, Switches, Pilot Lights, Control Stations and Joysticks

Product ID

26928

In Stock
Last updated: 2025/4/20
View Specifications
schneider ZB6EM6B

Selling Points

  • 1Blue LED Illumination: The ZB6EM6B features an integral blue LED light source for clear visibility.
  • 2IP65 Protection: Designed with IP65 protection, ensuring the product withstands various environmental conditions.
  • 3230-240V AC Operation: Compatible with 230-240V AC, making it suitable for a wide range of applications.
  • 4Compact Dimensions: Measuring 14 mm in height and 58 mm in depth, it fits seamlessly into restricted spaces.
  • 5Sustainable Design: Made from sustainable materials, aligning with green premium product standards.
Product Details
ZB6EM6B
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Range of Product
Harmony XB6
Product or Component Type
Complete body for pilot lights
Device short name
ZB6
Sale per indivisible quantity
5
Connections - terminals
Faston connectors 2.8 x 0.5 mm
Light source
LED
Bulb base
Integral LED
Light block supply
Direct
Light source colour
Blue
[Us] Rated Supply Voltage
230...240 V AC
CAD overall height
0.6 in (14 mm)
CAD overall depth
2.3 in (58 mm)
Terminals description ISO n°1
(X1-X2)PL
Net Weight
0.007 lb(US) (0.003 kg)
Operating position
Any position
[Ui] rated insulation voltage
250 V 3)EN/IEC 60947-1
[Uimp] rated impulse withstand voltage
4 kV EN 60947-1
Signalling type
Steady
Supply voltage limits
195…264 V AC
Surge withstand
1 kV in contact IEC 61000-4-5<br />2 kV in free air IEC 61000-4-5
Protective treatment
TC
Ambient Air Temperature for Storage
-40…158 °F (-40…70 °C)
Ambient Air Temperature for Operation
-13…158 °F (-25…70 °C)
Electrical shock protection class
Class II IEC 61140
Standards
JIS C 4520<br />CSA C22.2 No 14<br />EN/IEC 60947-5-1<br />UL 508<br />EN/IEC 60947-1<br />EN/IEC 60947-5-5<br />JIS C 852
Product Certifications
CSA<br />CCC<br />UL<br />GOST
Vibration resistance
+/- 3 mm 2…500 Hz)IEC 60068-2-6<br />5 gn 2…500 Hz)IEC 60068-2-6
Shock resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27<br />50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Resistance to fast transients
2 kV IEC 61000-4-4
Resistance to electromagnetic fields
9.1 V/m (10 V/m) IEC 61000-4-3
Resistance to electrostatic discharge
6 kV on contact (on metal parts) IEC 61000-2-6<br />8 kV in free air (in insulating parts) IEC 61000-2-6
Electromagnetic emission
Class B IEC 55011

Specifications may be subject to change without notice
