schneiderPushbuttons, Switches, Pilot Lights, Control Stations and Joysticks
Product Model

ZBYLEG302000

Manufacturer

schneider

Category

Pushbuttons, Switches, Pilot Lights, Control Stations and Joysticks

Product ID

28769

In Stock
Last updated: 2025/4/20
View Specifications
schneider ZBYLEG302000

Selling Points

  • 1Withstands harsh environments for reliable performance.
  • 2Quick and simple installation process.
  • 3Compatible with screw clamp, connector, Faston connector, spring terminal, or printed circuit board.
  • 4Made with recycled cardboard to reduce environmental impact.
  • 5Designed for use with various Schneider Electric control and signaling units.
Product Details
ZBYLEG302000
schneider

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Product or Component Type
Legend panel
accessory / separate part category
Marking accessories
Material
Plastic
Device Composition
Blank panel
Accessory / separate part destination
Ø 16 mm control and signalling units<br />Ø 22 mm control and signalling units<br />Ø 30 mm control and signalling units<br />For standard head
Range Compatibility
Harmony XB4<br />Harmony XB5<br />Harmony XB6<br />Harmony 9001K
Legend holder size
300 x 200
Marking
unmarked
Net Weight
0.066 lb(US) (0.030 kg)
Standards
ISO 21702<br />ISO 22196:2011

Specifications may be subject to change without notice
