Product Model
GRTE18S-F231X
Selling Points
- 1High Reliability: Designed for consistent performance in demanding industrial environments.
- 2Versatile Options: Available in various types of light sources (visible red light and infrared) to suit different detection needs.
- 3Efficient Design: Low power consumption (≤ 30 mA) and compact size for easy integration.
- 4Adjustable Sensitivity: Potentiometer for adjusting sensitivity to optimize detection accuracy.
- 5Durable Construction: Built with durable materials and robust mechanical design for long service life (up to 100,000 hours).
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Functional principle | Photoelectric proximity sensor | Functional principle detail | Energetic |
Dimensions (W x H x D) | 18 mm x 18 mm x 38.1 mm | Housing design (light emission) | Cylindrical |
Thread diameter (housing) | M18 x 1 | Optical axis | Radial, fully flush |
Sensing range max. | 3 mm ... 115 mm | Sensing range | 5 mm ... 100 mm |
Type of light | Visible red light | Light source | PinPoint LED |
Light spot size (distance) | Ø 8 mm (100 mm) | Wave length | 650 nm |
Adjustment | Potentiometer, 270° | Indication_LED green | Operating indicatorStatic on: power on |
Indication_LED yellow | Status of received light beamStatic on: object presentStatic off: object not present | Supply voltage UB | 10 V DC ... 30 V DC |
Ripple | < 5 V | Current consumption | 30 mA |
Switching output | PNP | Switching mode | Dark switching |
Signal voltage PNP HIGH/LOW | V#!#- (≤ 3 V) / approx. 0 V | Output current Imax. | ≤ 100 mA |
Response time | < 1,000 µs | Switching frequency | 500 Hz |
Connection type | Connector M12, 3-pin | Circuit protection | A6)#!#B7)#!#D8) |
Protection class | III | Housing material | Metal, Nickel-plated brass and ABS |
Optics material | Plastic, PMMA | Enclosure rating | IP67 |
Items supplied | Fastening nuts (2 x) | Electromagnetic compatibility (EMC) | EN 60947-5-2 |
Ambient operating temperature | –25 °C ... +55 °C | Ambient temperature, storage | –40 °C ... +70 °C |
UL File No. | NRKH.E348498 & NRKH7.E348498 |
Specifications may be subject to change without notice
