Product Model
GSE6-CA021K00
Selling Points
- 1High precision photoelectric sensing for accurate detection.
- 2Robust design for reliable operation in harsh environments.
- 3Easy integration with various industrial control systems.
- 4Compact and space-efficient design for minimal installation footprint.
- 5Compatible with a wide range of industrial automation systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Device version | FlexChain Guest | Sensor principle | Sender/receiver#!#Light grid system |
Light source | PinPoint LED, Infrared light | Light spot size (distance) | Ø 375 mm (12 m) |
Wave length | 850 nm | Supply voltage Vs | 12 V, via FlexChain (host) |
Adjustment | Cable (Sensitivity)#!#Via FlexChain (host) | Dimensions (W x H x D) | 12 mm x 31.5 mm x 21 mm |
Connection type | Male connector M8, 4-pin, Cable with female connector, M8, 4-pin, 0.5 m | Housing material | Plastic (ABS) |
Enclosure rating | IP65, IP67 | Protection class | III |
Weight | Approx. 23 g | Operating range | 15 m |
Specifications may be subject to change without notice
