Product Model
GTB2F-F1341
Selling Points
- 1High precision optical sensor for accurate distance measurement.
- 2Reliable performance in various industrial environments.
- 3Compact design for easy integration into systems.
- 4Durable construction with long-lasting components.
- 5Versatile application in AGV safety and automation systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Functional principle | Photoelectric proximity sensor | Functional principle detail | Background suppression |
Dimensions (W x H x D) | 14 mm x 24 mm x 3.5 mm | Housing design (light emission) | Rectangular |
Minimum detectable object (MDO) | 0.1 mm | Sensing range max. | 0 mm ... 9 mm |
Sensing range | 0 mm ... 8 mm | Type of light | Visible blue light |
Light source | PinPoint LED | Light spot size (distance) | Ø 1.5 mm (4 mm) |
Wave length | 455 nm | Adjustment | None |
Supply voltage UB | 10 V DC ... 30 V DC | Ripple | < 5 V |
Current consumption | 20 mA | Switching output | PNP |
Switching mode | Dark switching | Output current Imax. | ≤ 50 mA |
Response time | < 0.625 ms | Switching frequency | 800 Hz |
Connection type | Cable, 3-wire, 2 m | Cable material | Plastic, PVC |
Cable diameter | Ø 2.3 mm | Circuit protection | A6)#!#C7)#!#D8) |
Weight | 24.1 g | Housing material | Plastic, VISTAL® |
Optics material | Plastic, MABS | Enclosure rating | IP67 |
Ambient operating temperature | –20 °C ... +50 °C | Ambient temperature, storage | –40 °C ... +70 °C |
UL File No. | NRKH.E348498 & NRKH7.E348498 | Repeatability (Tanot constant) | 0.1 mm |
Hysteresis | < 0.3 mm |
Specifications may be subject to change without notice
