Product Model
GTE2F-F1111
Selling Points
- 1Compact design with dimensions 14 mm x 24 mm x 3.5 mm.
- 2Energetic detection principle for precise object detection.
- 3IP67 rating for robust and dust-resistant operation.
- 4DC voltage type with a supply range of 10 V DC to 30 V DC.
- 5Suitable for various applications including compact plants and robotics systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Functional principle | Photoelectric proximity sensor | Functional principle detail | Energetic |
Dimensions (W x H x D) | 14 mm x 24 mm x 3.5 mm | Housing design (light emission) | Rectangular |
Minimum detectable object (MDO) | 0.1 mm | Sensing range max. | 1.5 mm ... 15 mm |
Sensing range | 2 mm ... 12.5 mm | Type of light | Visible red light |
Light source | PinPoint LED | Light spot size (distance) | Ø 11 mm (15 mm) |
Wave length | 660 nm | Adjustment | None |
Supply voltage UB | 10 V DC ... 30 V DC | Ripple | < 5 V |
Current consumption | 20 mA | Switching output | PNP |
Switching mode | Dark switching | Output current Imax. | ≤ 50 mA |
Response time | < 0.625 ms | Switching frequency | 800 Hz |
Connection type | Cable, 3-wire, 2 m | Cable material | Plastic, PVC |
Cable diameter | Ø 2.3 mm | Circuit protection | A6)#!#C7)#!#D8) |
Weight | 22 g | Housing material | Plastic, VISTAL® |
Optics material | Plastic, MABS | Enclosure rating | IP67 |
Shock resistance | 294 m/s² (approx. 30 g, 6 shocks in x-, y-, z-axis) | Vibration resistance | 10 Hz ... 55 Hz (amplitude 0.5 mm, x-, y-, z-axis 0.5 hours (each direction))#!#138 m/s² 10 Hz ... 2,000 Hz (approx. 14 g, x-, y-, z-axis 2 hours) |
Ambient operating temperature | –20 °C ... +50 °C | Ambient temperature, storage | –40 °C ... +70 °C |
UL File No. | NRKH.E348498 & NRKH7.E348498 | Repeatability (Tanot constant) | 0.1 mm |
Hysteresis | < 2.25 mm |
Specifications may be subject to change without notice
