High-Quality Inductive Proximity Sensor IQR80-75NPPKC0S by SICK

Selling Points

1Precision Sensing Range: Detects objects up to 75mm with high accuracy.
2IP68 Enclosure Rating: Ensures robust protection against dust and water.
3Complementary PNP Output: Provides clear switching signals for reliable control.
4Wide Operating Voltage: Compatible with 10V to 30V DC, offering flexibility in setup.
5Long-Lasting Performance: Designed with a MTTFD of 139 years for extended service life.

Detailed engineering parameters based on manufacturer documentation

Parameter	Value	Parameter	Value
Housing	Rectangular	Dimensions (W x H x D)	80 mm x 40 mm x 114 mm
Sensing range Sn	75 mm	Safe sensing range Sa	60.7 mm
Installation type	Non-flush	Switching frequency	250 Hz
Connection type	Male connector M12, 4-pin	Switching output	PNP
Output function	Complementary	Electrical wiring	DC 4-wire
Enclosure rating	IP68	Special features	Reduction factor 1, Weld immune
Special applications	Welding range	Supply voltage	10 V DC ... 30 V DC
Ripple	≤ 10 %	Voltage drop	≤ 1.8 V
Hysteresis	3 % ... 15 %	Reproducibility	≤ 2 %
Temperature drift (of Sr)	≤ ± 10 %	Continuous current Ia	≤ 200 mA
No load current	≤ 15 mA	Off-state current	≤ 0.1 mA
Short-circuit protection	✔	Magnetic field strength	≤ 100 mT
Shock and vibration resistance	30 g, 11 ms / 10 ... 55 Hz, 1 mm	Ambient operating temperature	–25 °C ... +70 °C
Housing material	Plastic, PBT	Sensing face material	Plastic, PBT
Tightening torque, max.	Typ. 4 Nm	Protection class	II
UL File No.	E191603	Note	The values are reference values which may vary
Reduction factor	Reduction factor 1	Stainless steel (V2A, 304)	1
Aluminum (Al)	1	Copper (Cu)	1
Brass (Br)	1	Remark	Associated graphic see "Installation"
A	20 mm	B	160 mm
C	80 mm	D	185 mm
E	40 mm	F	450 mm
G	80 mm

Specifications may be subject to change without notice
