Product Model
RE13-SA64

Selling Points
- 1Detects objects with high immunity to ambient light and ensures precise detection.
- 2Quick and easy setup with a precise 5-turn potentiometer or teach function.
- 3Utilizes SICK ASIC technology for high performance and excellent reliability.
- 4Rugged mounting system with M3 threaded metal inserts reduces maintenance costs.
- 5Suitable for various industrial applications due to its reliable detection of shiny or jet-black objects.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Parameter | Value | Parameter | Value |
---|---|---|---|
System part | Sensor with actuator | Sensor principle | Magnetic |
Number of N/O contacts | 2 | Number of N/C contacts | 0 |
Number of signaling contacts | 0 | Safe switch on distance Sao | 7 mm |
Safe switch off distance Sar | 20 mm | Active sensor surfaces | 1 |
Actuation directions | 3 | Safe series connections | With Flexi Loop (with diagnostics) |
Connection type_Length of cable | 0.2 m | Connection type_Cable diameter | 5.8 mm |
Connection type_Conductor cross section | 0.25 mm² | Connection type_Bend radius (with fixed installation) | > 12 x cable diameter |
Connection type_Bend radius (with moving cable) | > 15 x cable diameter | Connection type_Cable material | PVC |
Connection type_Conductor material | Copper | Connection type_Coupling nut material | Nickel-plated brass |
Type of output | Reed contacts | Switching voltage | ≤ 30 V DC |
Switching current | ≤ 100 mA | Design | Rectangular |
Dimensions (W x H x D) | 26 mm x 36 mm x 13 mm | Weight | 0.1 kg |
Housing material | VISTAL® |
Specifications may be subject to change without notice
