Product Model
3KD4830-0QE10-0
Selling Points
- 1Standard tolerance compensation for precise alignment.
- 2Robust construction for long-lasting performance.
- 3Size 100 x 100 mm with a shaft diameter of 10 x 10 mm.
- 4Complete unit with a handle size of 100 mm.
- 5Ideal for applications requiring high precision and reliability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
DC Insulation Voltage (V) | 220VDC/440VDC/1000VDC | AC Rated Voltage (V) | 690 |
Insulation Voltage (V) | 1000 | Description | 3KD Specification 4; Rated Current 800A, 3P, Basic Unit, No Handle, Front Operation Mechanism on the Left Side of the Switch, Surface Mount, Flat Connection, |
Mounting Type | Surface Mount | Terminal Type | Flat Connection |
Number of Poles | 3P | In(A) | 800 |
Specification | 3KD Specification 4 [500-1000A] | Switch Type | Basic Unit, No Handle, Front Operation Mechanism on the Left Side of the Switch |
Lifecycle | Delivery Release (PM300) | Country of Origin | China |
ECCN | N | AL | N |
Model Number | 3KD4830-0QE10-0 |
Specifications may be subject to change without notice
