Product Model
3LD2013-0TK53
Selling Points
- 1High Safety Standards: Meets EN 60204 machinery directive for safe operation.
- 2Efficient Design: Floor mounting with door for easy access and operation.
- 3Robust Construction: IP65 enclosure for protection against dust and water.
- 4Versatile Application: Suitable for multiple applications in industrial settings.
- 5Reliable Performance: 7.5 kW operating power at AC-23 A 400 V.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
AC Rated Voltage(V): | 690 | Insulation Voltage(V): | 690 |
Description | Isolator switch, main control and emergency stop switch, 3LD2, 16A, 3P, rotary operating mechanism with door coupling, red/yellow handle, base-mounted installation, four-hole mounting on cabinet door, AC-23A/7.5KW | Installation Type: | Base-mounted installation, four-hole mounting on cabinet door |
Other: | AC-23A/7.5KW | Poles: | 3P |
In(A): | 16 | Specification: | 3LD20【16A】 |
Switch Type: | Rotary operating mechanism with door coupling, red/yellow handle | Lifecycle | Delivery Release (PM300) |
Country of Origin | Germany | ECCN | N |
AL | N | Model Number | 3LD2013-0TK53 |
Specifications may be subject to change without notice
