Product Model
3LD2250-0TK11
Selling Points
- 13-Pole Design: Suitable for various electrical applications.
- 232 A Uninterrupted Current: Ensures reliable operation under load.
- 311.5 kW Operational Power: Handles high power requirements with ease.
- 4Front-Mounted with Knob-Operated Mechanism: Easy to use and install in panel doors.
- 5Black Finish: Durable and aesthetically pleasing design.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
AC Rated Voltage (V) | 690 | Insulation Voltage (V) | 690 |
Description | Isolator switch, main control and emergency stop switch, 3LD2, 32A, 3P, with selector switch operation mechanism, black handle, mounting in the center hole of the cabinet door, AC-23A/11.5KW | Installation Type | Mounting in the center hole of the cabinet door |
Other | AC-23A/11.5KW | Number of Poles | 3P |
In(A) | 32 | Specification | 3LD22【32A】 |
Switch Type | With selector switch operation mechanism, black handle | Lifecycle | Delivery Release (PM300) |
Country of Origin | Germany | ECCN | N |
AL | N | Model Number | 3LD2250-0TK11 |
Specifications may be subject to change without notice
