Product Model
3LD2418-7UL01
Selling Points
- 1Reliable Power Distribution: The 3LD2418-7UL01 ensures stable power supply up to 250 A.
- 2Floor Mounting with Door Coupling: Easy installation with a door-coupling rotary operating mechanism.
- 3IP65 Protection: High degree of protection against dust and water, ensuring durability.
- 4Lockable Mechanism: Lockable in 0 position with up to 3 padlocks for secure operation.
- 5Efficient Switching: Fast and efficient switching operation with minimal downtime.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
AC Rated Voltage(V): | 690 | Insulation Voltage(V): | 690 |
Description | Isolator switch, main control and emergency stop switch, 3LD2, 250A, 3P+N, transfer switch with selector switch operation mechanism, black handle, flush mounting, four-hole fixation in cabinet door, AC-3/110KW; AC-23A/132KW | Installation Type: | Flush mounting in cabinet door with four-hole fixation |
Other: | AC-3/110KW; AC-23A/132KW | Poles: | 3P+N |
In(A): | 250 | Specification: | 3LD24【250A】 |
Switch Type: | Transfer switch with selector switch operation mechanism, black handle | Lifecycle | Delivery Release (PM300) |
Country of Origin | Germany | ECCN | N |
AL | N | Model Number | 3LD2418-7UL01 |
Specifications may be subject to change without notice
