Product Model
3NE3222
Selling Points
- 1Fast-acting switch-off characteristic for quick protection against overloads and short circuits.
- 2Semiconductor protection ensures reliable protection of power semiconductors.
- 3High rupture capacity (100 kA) for effective circuit breaking.
- 4Front indicator for easy visual monitoring of fuse status.
- 5Compliant with IEC and UL standards, suitable for global use in various applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Description | SITOR Fuse Size 1 aR 125A 1000VAC with Slotted Blade Contacts and Front-end Alarm Indicator | Rated Voltage | 1000VAC |
Type | aR [Semiconductor Partial Range Protection (Short Circuit Protection)] | Rated Current In (A) | 125 |
Specifications | Size: 1 [100-450A] | Lifecycle | Delivery Release (PM300) |
Country of Origin | Germany | ECCN | N |
AL | N | Model | 3NE3222 |
Specifications may be subject to change without notice
