Product Model
3RH7140-1AB00
Selling Points
- 1High-Performance Operation: Designed for reliable operation in harsh conditions with insulation voltage up to 690 V and surge voltage resistance of 6 kV.
- 2Versatile Connectivity: Compatible with 50/60 Hz frequencies and equipped with screw terminals for easy connection.
- 3Robust Design: Built with a frame size S00 and suitable for safety-related switching OFF applications.
- 4Long Service Life: Offers a mechanical service life of up to 30 million operating cycles.
- 5Compliant with Regulations: Meets RoHS directive since October 1, 2009, and is compliant with WEEE (2012/19/EU) take-back obligations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Number of Main Contacts | 4-pole | Rated Current | AC-15: 6A |
Lifecycle | Delivery Release (PM300) | Country of Origin | China |
ECCN | N | AL | N |
Model Number | 3RH7140-1AB00 |
Specifications may be subject to change without notice
