Product Model
3RT7014-1AF01
Selling Points
- 1Handles up to 5.5 kW at 400 V.
- 2Operates at 50/60 Hz with a control supply voltage of 110 V AC.
- 3Mechanical service life of 30 million switching cycles.
- 4Meets IP20 protection class for front and terminal connections.
- 5Available in size S00 with screw terminal connections.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Frame Size Code | S00 Specification | Number of Normally Open Auxiliary Contacts | 1 |
Main Contact Configuration | 3NO | Number of Poles | 3-pole |
Rated Current (A) | AC-3 6A | Lifecycle | Delivery Release (PM300) |
Country of Origin | China | ECCN | N |
AL | N | Model Number | 3RT7014-1AF01 |
Specifications may be subject to change without notice
