Product Model
3SE5122-0PA00
Selling Points
- 1Designed for safety applications up to Category 4 according to ISO 13849-1 (EN 954-1).
- 2Quick and easy installation, wiring, and maintenance due to its modular design.
- 3Metal housing with IP66/IP67 protection, suitable for harsh environments.
- 43x M20 x 1.5 cable entries for flexible connection options.
- 5Mechanical life of 15,000,000 cycles and electrical endurance of 100,000 cycles at AC-15.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Packaging Quantity | 1 | Quantity Unit | 1 Piece |
Package size unit of measure | MM | Packaging Dimension | 43,00 x 67,00 x 118,00 |
Net Weight (kg) | 0,379 Kg | Estimated dispatch time (Working Days) | 5 Day/Days |
Export Control Regulations | AL : N / ECCN : N | Product Lifecycle (PLM) | PM300:Active Product |
Product family | Enclosure width 56 mm | Product Description | Basic switch for position switch 3SE5112 Metal enclosure 56 mm 3x (M20x 1.5) 2 NO/1 NC slow-action contacts without actuator head |
Article Number (Market Facing Number) | 3SE5122-0PA00 |
Specifications may be subject to change without notice
