Product Model
5SM2345-6KK01
Selling Points
- 1Reliable Protection: Provides short-time delayed protection against electrical faults.
- 2High Current Capacity: Handles currents up to 63 A for robust power distribution.
- 3Compliance with Standards: Meets IEC/EN 61008 and VDE 0664-10 standards for safety and efficiency.
- 4Versatile Installation: Suitable for various installation configurations, including top and bottom mains connections.
- 5Durable Design: Built to withstand ambient temperatures from -40°C to +75°C and 28 cycles of climate resistance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Description | 5SM2 A(K) 30mA 4P 63A; Rated Current 63A; 4P; Residual Current 30mA; A(K); Electromagnetic | Testing Method: (ELE: Electronic, ELM: Electromagnetic) | Electromagnetic |
Leakage Current Type: | A(K) | Residual Current: | 30mA |
Product Type: | Residual Current Protection Module | Number of Poles: | 4P |
In(A): | 63 | Lifecycle | Delivery Release (PM300) |
Country of Origin | Germany | ECCN | EAR99 |
AL | N | Model Number | 5SM2345-6KK01 |
Specifications may be subject to change without notice
