Product Model
5SM2626-8
Selling Points
- 1Advanced Electrical Protection: Safeguard your electrical system with the 5SM2626-8's selective and instantaneous residual current protection.
- 2High Current Capacity: Handles up to 63 A with a rated residual current of 300 mA, ensuring robust protection.
- 3Easy Installation: Designed for simple bus mounting with standard pin busbars, reducing installation time and complexity.
- 4Long Service Life: Equipped with patented active condensation protection, extending the device's lifespan and reducing maintenance needs.
- 5Compliance with Standards: Meets IEC/EN 61008-1 and VDE 0664-10 standards for reliable and safe operation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Type | Residual Current Protection Module | Number of Poles | 2P |
Description | 5SM2_For 5SN4 & 5SL4 RC-Unit; rated current 63A; 2P; residual current 300mA; A(S); electromagnetic | Detection Method (ELE electronic, ELM electromagnetic) | Electromagnetic |
Residual Current Type | A(S) | Residual Current | 300mA |
Rated Current In(A) | 63 | Lifecycle | Delivery Release (PM300) |
Country of Origin | Germany | ECCN | N |
AL | N | Model Number | 5SM2626-8 |
Specifications may be subject to change without notice
