Product Model
5TR2333-7CC16
Selling Points
- 1Advanced Transfer Switch: Designed for reliable electrical distribution with IEC 60947-6-1 compliance.
- 2Class CB Certification: Meets stringent safety standards for electrical equipment.
- 3High Current Capacity: Handles up to 10 kA, ensuring robust performance in demanding applications.
- 43-Pole Configuration: Suitable for a wide range of electrical systems requiring three-phase power distribution.
- 5Enhanced Functions: Includes additional features for enhanced functionality and control.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Description | 5TR2 CB-16A-3P10C; CB Level; Rated Current 16A; 3P 10kA C Curve Equipped with 5SJ4 Miniature Circuit Breaker | Withstand Voltage (kV) | 4 |
Application Type | AC-33B [Mixed Loads of Resistive and Inductive, Including Moderate Overload] | System Voltage | 230/400VAC |
Control Voltage | 230VAC | Trip Unit | C [C Characteristic Curve] |
Breaking Capacity (kA) | 10 | Number of Poles | 3 |
In(A) | 16 | Control Type | Smart Type |
Type | CB Level | Lifecycle | Delivery Release (PM300) |
Country of Origin | China | ECCN | N |
AL | N | Model Number | 5TR2333-7CC16 |
Specifications may be subject to change without notice
