Product Model
6EP3332-7SB00-0AX0
Selling Points
- 1High efficiency with minimal energy losses (<1 W no-load operation).
- 2Wide operating temperature range from -25°C to 70°C.
- 3Push-in connections for fast and secure wiring.
- 4International standards compliance and NEC class 2 certification.
- 5Reliable output voltage regulation with ±3% total tolerance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated Output Power | 60W | Input Voltage Range | AC 85-264V (DC 110-275V) |
Number of Power Phases | Single phase AC or DC | Rated Output Current | 2.5A |
Rated Output Voltage | DC 24V | Rated Input Voltage | AC 120-240V (DC 120-240V) |
Lifecycle | P.M300 | Country of Origin | Germany |
ECCN | N | AL | N |
Model Number | 6EP3332-7SB00-0AX0 |
Specifications may be subject to change without notice
