Product Model
6ES7132-6BF01-0AA0
Selling Points
- 1The 6ES7132-6BF01-0AA0 module features 8x 24V DC/0.5A basic source outputs, ensuring reliable and efficient digital control.
- 2Equipped with advanced diagnostics, including monitoring of supply voltage, wire-break detection, and short-circuit protection, for enhanced module health.
- 3Configurable and integrated with STEP 7 TIA Portal from version V14, making it easy to integrate into your existing automation systems.
- 4Designed for efficient operation with low power loss (typical 1 W) and minimal current consumption (max. 45 mA).
- 5Supports various connection variants including 1-wire, 2-wire, and 3-wire connections with AUX terminals or potential distributor modules.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Packaging Quantity | 1 | Quantity Unit | 1 Piece |
Package size unit of measure | MM | Packaging Dimension | 150,00 x 200,00 x 30,00 |
Net Weight (kg) | 0,037 Kg | Estimated dispatch time (Working Days) | 20 Day/Days |
Export Control Regulations | AL : N / ECCN : N | Notes | Please enter text for every Y option (using the Configurator). |
Product Lifecycle (PLM) | PM300:Active Product | Product family | Actuators and indicators, 22 mm, round, plastic, black |
Product Description | Indicator lights, 22 mm, round, plastic, red, lens, smooth, with holder, LED module, with integrated LED 230 V AC, screw terminal, with laser labeling, inscription or symbol Customer-specific selection with SIRIUS ACT configurator (CIN) | Article Number (Market Facing Number) | 3SU1106-6AA20-1AA0-Z Y19 |
Specifications may be subject to change without notice
