Product Model
6ES7222-1BD30-0XB0
Selling Points
- 1High-Performance Digital Output Module: The 6ES7222-1BD30-0XB0 is designed for high-speed applications with a switching frequency of 200 kHz.
- 2Robust Short-Circuit Protection: Equipped with solid-state MOSFET outputs and short-circuit protection to ensure reliable operation.
- 3Compact Design: Measuring 38mm x 62mm x 21mm, this module is compact and easy to integrate into your system.
- 4Wide Operating Temperature Range: Operates between -20°C to 60°C (horizontal) and -20°C to 50°C (vertical), making it suitable for various environments.
- 5Comprehensive Certifications: Meets CE, CSA, UL, cULus, FM, RCM, and KC standards for global compatibility and safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Packaging Quantity | 1 | Quantity Unit | 1 Piece |
Package size unit of measure | MM | Packaging Dimension | 150,00 x 200,00 x 30,00 |
Net Weight (kg) | 0,037 Kg | Estimated dispatch time (Working Days) | 20 Day/Days |
Export Control Regulations | AL : N / ECCN : N | Notes | Please enter text for every Y option (using the Configurator). |
Product Lifecycle (PLM) | PM300:Active Product | Product family | Actuators and indicators, 22 mm, round, plastic, black |
Product Description | Indicator lights, 22 mm, round, plastic, red, lens, smooth, with holder, LED module, with integrated LED 230 V AC, screw terminal, with laser labeling, inscription or symbol Customer-specific selection with SIRIUS ACT configurator (CIN) | Article Number (Market Facing Number) | 3SU1106-6AA20-1AA0-Z Y19 |
Specifications may be subject to change without notice
