Product Model
6ES7288-1SR20-0AA1
Selling Points
- 1Seamlessly communicate with other devices for easy programming and data exchange.
- 2Efficiently execute automation logic with powerful CPU processing power.
- 3Supports the addition of various expansion modules for increased functionality.
- 4Designed for industrial environments with robust housing and IP protection for dust and moisture.
- 5Includes high-speed counters, pulse outputs (PTO/PWM), and other advanced control functions.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Depth | 81mm | Height | 100mm |
Width | 90mm | PROFINET Ports | 1 |
Processor Speed (1K, binary operation) | 0.15ms | Digital Outputs | 8 |
Digital Inputs | 12 | Operating Voltage | 220V AC or 110V DC |
Model | SR20 | Type | Standard |
Product Type | CPU | Lifecycle | Delivery Release (PM300) |
Country of Origin | China | ECCN | EAR99H |
AL | N | Model Number | 6ES7288-1SR20-0AA1 |
Specifications may be subject to change without notice
