Product Model
7ME3723-7JK22-1UA3-ZA01B11E02F00S30T29
Selling Points
- 1Highly accurate flow measurement for industrial sectors.
- 2Suitable for water supply, crude oil, and gas transport pipelines.
- 3Clamp-on design for easy installation without process interruption.
- 4Reliable performance in harsh industrial environments.
- 5Compliant with REACH Regulation for safe use and disposal.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Medium Temperature | -40°C … 121°C | Separate Cable Length | 4*10m |
Software Function | Liquids, industrial standard applications | Output | HART, 4-20mA |
Transmitter Type | Cast aluminum wall-mounted enclosure, IP67; non-explosion proof | Sensor Type | Sensor D3; applicable pipe outer diameter 203-610mm |
Product Series | SITRANS FS230 | Product Type | Ultrasonic Flow Meter |
Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
ECCN | N | AL | N |
Model Number | 7ME3723-7JK22-1UA3-ZA01B11E02F00S30T29 |
Specifications may be subject to change without notice
