Product Model
7ML5630-0AA00-0JA0
Selling Points
- 1Detects level and interface in liquids, solids, slurries, and foam.
- 2Adjustable 5.5 m (18.04 ft) insertion for versatile application.
- 3Adaptable sensitivity to tune out build-up on probe.
- 4Durable construction with 316L stainless steel probe body.
- 5Dust ignition proof with CSA/FM Class II, III Div.1 Gr.E, F, G T4 approvals.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Electrical Interface and Protection Rating | 2*1/2"NPT, IP65 | Explosion Protection Type | Non-explosive-proof |
Probe Material | 19mm 316L hard rod with PPS coating | Wetted Seal Material | FKM |
Thermal Isolation | Standard | Measuring Rod Length | 120mm |
Process Connection and Material | 3/4"NPT, 316L stainless steel | Product Series | SITRANS CLS200 |
Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
ECCN | EAR99 | AL | N |
Model Number | 7ML5630-0AA00-0JA0 |
Specifications may be subject to change without notice
