Product Model
S55162-A108
Selling Points
- 1High Torque: 10 Nm torque for efficient operation.
- 2Precise Rotation: 90° rotation for precise positioning.
- 3AC Compatibility: Compatible with AC 230 V, 3-phase power.
- 4Manual Control: Manual control with the option to fix position.
- 5Customizable: Plug in space for auxiliary switch and/or potentiometer.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Operating Range | DC 0…10 V | Operating Voltage | AC 230 V |
Positioning Time | 3-bit | Positioning Signal | 3-bit |
Installation Position | Perpendicular to the horizontal plane | Power Consumption | 3.5 VA |
Lifecycle | P.M300 | Country of Origin | Switzerland |
ECCN | 9N9999 | AL | N |
Model | S55162-A108 |
Specifications may be subject to change without notice
