Product Model
2009-114/000-012
Selling Points
- 1High-Quality Marking Solution: Ideal for smart printers with thermal transfer marking.
- 2Stretchable and Durable: 4 - 4.2 mm width, plain, snap-on type, ensuring long-lasting use.
- 3Orange Color: Easy to identify and use, perfect for various industrial applications.
- 4Convenient Packaging: 2000 pieces on a roll, reducing the need for frequent replacements.
- 5Halogen-Free and UV Resistant: Meets EN 60068-2-5:2010 Procedure B standards for reliability and safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Suitable | for WAGO Rail-Mount Terminal Blocks | Marking method | Thermal transfer |
Marking | plain | Delivery form | Roll |
Delivery form configuration | 2,000 WMB markers (4 mm)/reel | Flammability class per UL94 | V2 |
Printing device | Smart Printer (Thermal Transfer Printer) | Marker/strip width | 4 … 4.2?mm |
Marker width | 4mm | Smear resistance | in conjunction with 258-5005 Ink Ribbon |
Color | orange | UV resistance | EN 60068-2-5:2010 Procedure B |
Halogen-free | Yes | Weight | 115.7g |
eCl@ss 10.0 | 27-14-11-37 | eCl@ss 9.0 | 27-14-11-37 |
ETIM 9.0 | EC000761 | ETIM 8.0 | EC000761 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
Packaging type | bag | Country of origin | DE |
GTIN | 4055143367936 | Customs tariff number | 3926909985 |
RoHS Compliance Status | Compliant,No Exemption | Test specification <br/>Railway applications – <br/>Rolling stock – <br/>Electronic equipment | DIN EN 50155 (VDE 0115-200):2022-06 |
Test procedure <br/>Railway applications – <br/>Rolling stock equipment – <br/>Shock and vibration tests | DIN EN 61373 (VDE 0115-0106):2011-04 | Spectrum/Installation location | Service life test, Category?1, Class?A/B |
Function test with noise-like vibration | Test passed according to Section 8 of the standard | Frequency | f1= 5 Hz to f2= 150 Hz |
Acceleration | 5g (highest test level used for all axes) | Test duration per axis | 5 h |
Test directions | X, Y and Z axes | Monitoring for contact faults/interruptions | Passed |
Voltage drop measurement before and after each axis | Passed | Simulated service life test through increased levels of noise-like vibration | Test passed according to Section 9 of the standard |
Extended test scope: Monitoring for contact faults/interruptions | Passed | Extended test scope: Voltage drop measurement before and after each axis | Passed |
Shock test | Test passed according to Section 10 of the standard | Shock form | Half sine |
Shock duration | 30 ms | Number of shocks per axis | 3 pos. und 3 neg. |
Vibration and shock stress for rolling stock equipment | Passed |
Specifications may be subject to change without notice
