Product Model
2020-2292
Selling Points
- 11 mm Thickness: Durable and robust construction.
- 2UL94 V0 Flammability Class: Meets stringent fire safety standards.
- 3Orange Color: Easy identification in complex systems.
- 4Rail/Chassis Mount: Designed for versatile terminal block applications.
- 5Packaging in Multiples of 25: Convenient for bulk orders and inventory management.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 1?mm?/ 0.039?inches | Height | 79.5?mm?/ 3.13?inches |
Depth | 51.1?mm?/ 2.012?inches | Mounting type | snap-on type |
Note (material data) | Information on material specifications can be found here | Color | orange |
Material group | I | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V0 | Fire load | 0.104MJ |
Weight | 3.5g | Product Group | 18 (X-COM-System) |
eCl@ss 10.0 | 27-14-11-33 | eCl@ss 9.0 | 27-14-11-33 |
ETIM 9.0 | EC000886 | ETIM 8.0 | EC000886 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 25?pcs |
Packaging type | box | Country of origin | DE |
GTIN | 4050821049661 | Customs tariff number | 8538906000 |
RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
