Product Model
2022-1691
Selling Points
- 1High-Quality Material: Made from durable 1mm thick gray material.
- 2Flammability Class V0: Meets stringent safety standards with a UL94 V0 flammability class.
- 3Compact Design: Measures 32.5 mm in depth and 52 mm in height.
- 4Packaging Type: Available in a convenient box packaging.
- 5Industrial Compatibility: Designed for use in rail/chassis terminal blocks, suitable for various industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 1?mm?/ 0.039?inches | Height | 52?mm?/ 2.047?inches |
Depth | 32.5?mm?/ 1.28?inches | Mounting type | snap-on type |
Note (material data) | Information on material specifications can be found here | Color | gray |
Material group | I | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V0 | Fire load | 0.053MJ |
Weight | 1.6g | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
