Product Model
210-742
Selling Points
- 1High-Quality Material: Made from durable polyester for long-lasting performance.
- 2Snap-On Design: Easy to install and secure on 15mm wide terminal blocks.
- 3Temperature Resistance: Operates in ambient temperatures from -40°C to +150°C.
- 4Halogen-Free: Compliant with safety standards, free from halogen materials.
- 5Customizable Reel Length: Available in a 20-meter reel for efficient use in various applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Marking method | Thermal transfer | Marking | plain |
Delivery form | Strip | Delivery form configuration | 20 m; 1?line |
Printing device | Smart Printer (thermal transfer printer) | Strip width | 15mm |
Mounting type | Snapping on | Smear resistance | EN 60998-1:2004 |
Color | white | UV resistance | EN 60068-2-5:2010 Procedure B |
Adhesive information | without adhesive | Halogen-free | Yes |
Weight | 80g | Ambient temperature (storage) | +10 … +21 °C |
Ambient temperature (operation) | -40 … +150 °C | Relative humidity | 40 … 50?% |
ETIM 9.0 | EC000761 | ETIM 8.0 | EC000761 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
Packaging type | Box | GTIN | 4066966255423 |
RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
