Product Model
210-853
Selling Points
- 1Halogen-Free Design: Ensures safety and compliance with industrial standards.
- 2Durable Polymers: Constructed from high-quality polymers for long-lasting performance.
- 3Easy Mounting: Push-in termination for solid and stranded conductors, including fine-stranded conductors with ferrules.
- 4Vibration-Proof: Industry-proven spring pressure connection technology for secure connections.
- 5Compact Dimensions: Measures 27mm x 19mm, perfect for various applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Height | 19?mm | Width | 27?mm |
Mounting type | Pushing in | Color | black |
Material | Polymers | Adhesive information | without adhesive |
Halogen-free | Yes | Weight | 1.8g |
Ambient temperature (storage) | +5 … +40 °C | Ambient temperature (operation) | +5 … +100 °C |
Relative humidity | 40 … 80?% | Product Group | 2 (Terminal Block Accessories) |
eCl@ss 10.0 | 27-14-40-75 | eCl@ss 9.0 | 27-14-40-75 |
ETIM 9.0 | EC002248 | ETIM 8.0 | EC002248 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 100?pcs |
Packaging type | box | Country of origin | DE |
GTIN | 4050821674931 | Customs tariff number | 3926909985 |
RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
