Product Model
216-151
Selling Points
- 10.75 mm ID x 1.7 mm OD barrel size for precise fitting.
- 2Crimped connection type for quick and secure termination.
- 3Suitable for solid and fine-stranded conductors in various applications.
- 4Electro-tin plated for enhanced durability and resistance.
- 5Available in bulk quantities at an affordable price ($0.02 per unit).
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Sleeve cross-section (AWG) | 24AWG | Sleeve for | 0.25mm2 |
Strip length | 5?mm?/ 0.2?inches | Length | 5mm |
Diameter | 1.7mm | Diameter crimp sleeve inside | 0.75mm |
Weight | 0g | Product Group | 2 (Terminal Block Accessories) |
eCl@ss 10.0 | 27-40-02-01 | eCl@ss 9.0 | 27-40-02-01 |
ETIM 9.0 | EC000005 | ETIM 8.0 | EC000005 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 5000?(1000)?pcs |
Packaging type | box | Country of origin | DE |
GTIN | 4017332277563 | Customs tariff number | 8536904000 |
RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
