Product Model
231-366/108-000
Selling Points
- 1Advanced EtherNet/IP Communication: Supports up to 250 connections per node and 64 field devices.
- 2Reliable Power Supply: Operates on a 24Vdc supply via system wiring and power jumper.
- 3Easy Configuration: Features a 4-pin male connector for device configuration.
- 4Durable Design: Mounted on a DIN-35 rail with an IP20 rating, suitable for ambient temperatures from 0°C to +55°C.
- 5Versatile Connectivity: Includes two RJ45 connectors for fieldbus and spring CAGE CLAMP for power supply connections.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Safety information | TheMCS – MULTI CONNECTION SYSTEMincludes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load.When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure header pins, which can be touched, are not live when unmated. | Variants: | Other pole numbers |
Total number of potentials | 6 | Number of connection types | 1 |
Number of levels | 1 | Pin spacing | 5.08?mm?/ 0.2?inches |
Width | 40.48?mm?/ 1.594?inches | Height | 17?mm?/ 0.669?inches |
Height from the surface | 12?mm?/ 0.472?inches | Depth | 8.4?mm?/ 0.331?inches |
Solder pin length | 5mm | Solder pin dimensions | 1.2 x 1.2?mm |
Drilled hole diameter with tolerance | 1.7(+0.1)mm | Variable coding | Yes |
Anti-rotation protection | Yes | Contact type (pluggable connector) | Male connector/plug |
Connector (connection type) | for PCB | Mismating protection | No |
Plugging without loss of pin spacing | No | Mating direction to the PCB | 90° |
Locking of plug-in connection | Threaded flange | PCB contact | THT |
Solder pin arrangement | over the entire male connector (in-line) | Number of solder pins per potential | 1 |
Note (material data) | Information on material specifications can be found here | Color | orange |
Material group | I | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V0 | Contact material | Electrolytic copper (ECu) |
Contact plating | Tin | Fire load | 0.048MJ |
Weight | 3.1g | Limit temperature range | -60 … +100?°C |
Processing temperature | -35 … +60?°C | Product Group | 3 (Multi Conn. System) |
eCl@ss 10.0 | 27-44-04-02 | eCl@ss 9.0 | 27-44-04-02 |
ETIM 9.0 | EC002637 | ETIM 8.0 | EC002637 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 100?pcs |
Packaging type | box | Country of origin | PL |
GTIN | 4045454845667 | Customs tariff number | 8536694040 |
CAS-No. | 7439-92-1 | REACH Candidate List Substance | Lead |
RoHS Compliance Status | Compliant,With Exemption | RoHS Exemption | 6(c) |
SCIP notification number (Austria) | cb1170de-c54c-4540-b2bc-4342167ee89b | SCIP notification number (Belgium) | 5f886315-35eb-4d50-8c1e-071693676b90 |
SCIP notification number (Bulgaria) | 57555c28-1c62-4ba4-b146-c5a8d16fb36d | SCIP notification number (Czech Republic) | 16e19d21-581f-482e-81ad-1b767fdabad2 |
SCIP notification number (Denmark) | f0d79477-133e-4f41-98ba-819b3bf093ec | SCIP notification number (Finland) | bdec9b9f-af2f-40c7-9ecc-b5dcd52dc94f |
SCIP notification number (France) | 54a5f2ee-a3ea-453e-9394-23e76b7bb6c3 | SCIP notification number (Germany) | 04eff709-af20-4028-854e-13fd5658a5bb |
SCIP notification number (Hungary) | c855143e-b80b-46a5-8b4b-7ba50918fe9a | SCIP notification number (Italy) | 806c8fd8-6e64-4874-839b-c1eb9a76a6b9 |
SCIP notification number (Netherlands) | cba0b939-1f46-486f-bfbb-c82502b1ae91 | SCIP notification number (Poland) | a847e339-3527-48de-94b7-89a2b6cafd11 |
SCIP notification number (Romania) | 6a2d4d58-0ace-426b-a9cc-1428e2ecbdeb | SCIP notification number (Sweden) | acfaef8d-f2f2-446f-be5d-ce4f8a6ae295 |
Ratings per | IEC/EN 60664-1 | Rated voltage (III / 3) | 250V |
Rated impulse voltage (III / 3) | 4kV | Rated voltage (III/2) | 320V |
Rated surge voltage (III/2) | 4kV | Nominal voltage (II/2) | 630V |
Rated surge voltage (II/2) | 4kV | Rated current | 16A |
Legend (ratings) | (III / 2) ? Overvoltage category III / Pollution degree 2 | Approvals per | CSA |
Rated voltage UL (Use Group B) | 300V | Rated current UL (Use Group B) | 15A |
Rated voltage UL (Use Group D) | 300V | Rated current UL (Use Group D) | 10A |
Rated voltage (UL 1977) | 600V | Rated current UL 1977 | 15A |
Rated voltage CSA (Use Group B) | 300V | Rated current CSA (Use Group B) | 15A |
Rated voltage CSA (Use Group D) | 300V | Rated current CSA (Use Group D) | 10A |
Number of poles | 6 | Test specification <br/>Railway applications – <br/>Rolling stock – <br/>Electronic equipment | DIN EN 50155 (VDE 0115-200):2022-06 |
Test procedure <br/>Railway applications – <br/>Rolling stock equipment – <br/>Shock and vibration tests | DIN EN 61373 (VDE 0115-0106):2011-04 | Spectrum/Installation location | Service life test, Category?1, Class?A/B |
Function test with noise-like vibration | Test passed according to Section 8 of the standard | Frequency | f1= 5 Hz to f2= 150 Hz |
Acceleration | 5g (highest test level used for all axes) | Test duration per axis | 5 h |
Test directions | X, Y and Z axes | Monitoring for contact faults/interruptions | Passed |
Voltage drop measurement before and after each axis | Passed | Simulated service life test through increased levels of noise-like vibration | Test passed according to Section 9 of the standard |
Extended test scope: Monitoring for contact faults/interruptions | Passed | Extended test scope: Voltage drop measurement before and after each axis | Passed |
Shock test | Test passed according to Section 10 of the standard | Shock form | Half sine |
Shock duration | 30 ms | Number of shocks per axis | 3 pos. und 3 neg. |
Vibration and shock stress for rolling stock equipment | Passed |
