Product Model
231-903
Selling Points
- 1Insulated Design: Ensures safe and reliable electrical connections.
- 23-Way Configuration: Perfect for multiple conductor entry points.
- 35 mm Pin Spacing: Compatible with 231 Series female connectors.
- 4High-Rated Current: Supports up to 16 A of current.
- 5Durable Construction: Made with polyamide (PA66) insulation material.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Pin spacing | 5/5.08?mm?/ 0.197/0.2?inches | Width | 15.3?mm?/ 0.602?inches |
Depth | 6.15?mm?/ 0.242?inches | Jumper assignment | 1-2-3 |
Suitable | for male and female connectors with CAGE CLAMP?connection | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.008MJ | Weight | 0.7g |
Product Group | 3 (Multi Conn. System) | eCl@ss 10.0 | 27-14-11-40 |
eCl@ss 9.0 | 27-14-11-40 | ETIM 9.0 | EC000489 |
ETIM 8.0 | EC000489 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454565848 |
Customs tariff number | 8536698000 | RoHS Compliance Status | Compliant,No Exemption |
Ratings per | IEC/EN 60664-1 | Rated voltage (III/2) | 320V |
Rated surge voltage (III/2) | 4kV | Rated current | 16A |
Legend (ratings) | (III / 2) ? Overvoltage category III / Pollution degree 2 | Number of poles | 3 |
Specifications may be subject to change without notice
