Product Model
232-636
Selling Points
- 1The WAGO 232-636 uses patented stainless steel clamping mechanisms for secure and reliable connections.
- 2Designed to handle up to 800 V, making it suitable for demanding industrial applications.
- 3Push-in termination allows for quick and tool-free insertion of conductors, reducing installation time.
- 4Built to withstand harsh environments and extreme temperatures, ensuring long-term performance.
- 5Compatible with a wide range of wire sizes from 0.25 to 2.5 mm², accommodating various industrial needs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Pin spacing | 5.08?mm?/ 0.2?inches | Width | 33?mm?/ 1.299?inches |
Height | 17.5?mm?/ 0.689?inches | Depth | 41.5?mm?/ 1.634?inches |
Suitable | for standard male and female connectors | Note (material data) | Information on material specifications can be found here |
Color | orange | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.222MJ | Weight | 7.4g |
Product Group | 3 (Multi Conn. System) | eCl@ss 10.0 | 27-14-11-92 |
eCl@ss 9.0 | 27-44-04-92 | ETIM 9.0 | EC002848 |
ETIM 8.0 | EC002848 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 25?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332283120 |
Customs tariff number | 8538908160 | RoHS Compliance Status | Compliant,No Exemption |
Number of poles | 6 |
Specifications may be subject to change without notice
