Product Model
243-113
Selling Points
- 1DIN-35 Rail and Screw Mounting Compatibility: Mounts directly to DIN-35 rail or via screw-mount flanges.
- 2Easy Connection for Smaller Conductors: Ideal for low-current applications, providing quick and easy connections.
- 3Terminates Telephone-Style Conductors: Well-suited for connecting alarms, bells, door sensors, and communication systems.
- 4Removable and Reusable: Connectors snap into mounting slots and are removable for conductor exchange during changeovers.
- 5Clear Circuit Identification: Large marking area for direct marking with permanent felt-tip pens or pre-printed marking strips.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 22.5 mm / 0.886 inches | Height | 50 mm / 1.968 inches |
Depth from upper-edge of DIN-rail | 10.7 mm / 0.421 inches | Depth | 15.5 mm / 0.61 inches |
Mounting type | DIN-35 rail | Suitable | for 6 connectors |
Note (material data) | Information on material specifications can be found here | Color | orange |
Fire load | 0.079MJ | Weight | 2.6g |
Product Group | 7 (Push Wire Conn.) | eCl@ss 10.0 | 27-14-11-92 |
eCl@ss 9.0 | 27-14-11-92 | ETIM 9.0 | EC002848 |
ETIM 8.0 | EC002848 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?(10)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332335492 |
Customs tariff number | 3926909985 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
