Product Model
249-138
Selling Points
- 1Robust CAGE CLAMP Connection: Secure and vibration-resistant connection technology.
- 2High Voltage Rating: Supports up to 800 V, ideal for demanding industrial environments.
- 3Versatile Conductor Range: Handles conductors from 0.14 to 1.5 mm², accommodating various wire sizes.
- 4Easy Termination: Push-in termination for solid conductors and screwdriver removal for fine-stranded conductors.
- 5Durable Design: Constructed with high-quality materials for long-lasting performance in harsh conditions.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 8?mm?/ 0.315?inches | Module width | 8?mm?/ 0.315?inches |
Note (material data) | Information on material specifications can be found here | Color | gray |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.104MJ | Weight | 1.3g |
Product Group | 2 (Terminal Block Accessories) | eCl@ss 10.0 | 27-14-11-48 |
eCl@ss 9.0 | 27-14-11-48 | ETIM 9.0 | EC002555 |
ETIM 8.0 | EC002555 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454359973 |
Customs tariff number | 8536904000 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | Lead | RoHS Compliance Status | Compliant,With Exemption |
RoHS Exemption | 6(c) | SCIP notification number (Austria) | 49b6921b-e745-4d6a-8ddb-6b3f340417a1 |
SCIP notification number (Belgium) | 50c873aa-ce13-4e30-ab4e-9adb59d94ded | SCIP notification number (Bulgaria) | c516e619-ab32-4af6-940d-597525c3081d |
SCIP notification number (Czech Republic) | 0865b9d0-1564-4972-816f-d53032665ef1 | SCIP notification number (Denmark) | 7bc54153-d8e9-452c-9d7a-687d508ee438 |
SCIP notification number (Finland) | 6be4f7a4-129f-484a-a4b0-103da2af6b83 | SCIP notification number (France) | 0bd316cb-03d1-4234-bcf8-45f5572ec581 |
SCIP notification number (Germany) | 6f2ba8d9-c1e3-4349-afac-95220f391089 | SCIP notification number (Hungary) | 4af9e7b7-693d-402c-a686-b557b400b255 |
SCIP notification number (Italy) | 17fe9b05-3091-4a41-8cdf-4ed7e1c170fe | SCIP notification number (Netherlands) | 1bf7fd6f-5723-455d-824b-90caf37ff4aa |
SCIP notification number (Poland) | 3df95b8e-68af-4906-8d33-889a86169935 | SCIP notification number (Romania) | 9dbfa58c-c2e9-47aa-98d1-3fc3489cff4e |
SCIP notification number (Sweden) | ade9cabc-dde1-4c62-b145-15b12ab45ec9 | Rated voltage (III / 3) | 500V |
Ratings (note) | Maximum test voltage (touch contact): 48 V (test pins are not touch-proof) | Ratings (note) 2 | Maximum test current (touch contact): 0.5 AMaximum test current: 6 A (if the test pins are securely connected in the clamping units) |
Test voltage | 500V | Test current | 0.5A |
Specifications may be subject to change without notice
