Product Model
257-801
Selling Points
- 1High-quality, durable design for long-lasting performance.
- 2Easy-to-use interface simplifies complex automation tasks.
- 3Compatible with various industrial protocols for seamless integration.
- 4Compact size reduces installation space requirements.
- 5Advanced diagnostics for quick issue resolution and reduced downtime.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Pin spacing | 5/5.08?mm?/ 0.197/0.2?inches | Width | 5.08?mm?/ 0.2?inches |
Height | 13.6?mm?/ 0.535?inches | Depth | 14.2?mm?/ 0.559?inches |
Use | extends pin spacing | Mounting type | snap-on type |
Note (material data) | Information on material specifications can be found here | Color | gray |
Material group | I | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V0 | Fire load | 0.016MJ |
Weight | 0.5g | Product Group | 4 (Printed Circuit Connectors) |
eCl@ss 10.0 | 27-44-04-92 | eCl@ss 9.0 | 27-44-04-92 |
ETIM 9.0 | EC002848 | ETIM 8.0 | EC002848 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 500?(100)?pcs |
Packaging type | box | Country of origin | CH |
GTIN | 4017332445344 | Customs tariff number | 3926909985 |
RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
