Product Model
264-367
Selling Points
- 1Ideal for DIN 15 rail applications, ensuring space efficiency in your electrical setup.
- 2Secure and reliable connections with insulated comb type jumper bars for enhanced safety.
- 3Built to withstand demanding electrical environments with a maximum current rating of 16 A.
- 4Available in various colors (grey, blue, orange, light grey) to match your specific needs.
- 5Simple push-in termination for quick and hassle-free installation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 4?mm?/ 0.157?inches | Height | 66?mm?/ 2.598?inches |
Depth | 40?mm?/ 1.575?inches | Note (material data) | Information on material specifications can be found here |
Color | orange | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.157MJ | Weight | 5.4g |
Product Group | 9 (Std Chassis Mt Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332253888 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
