Product Model
264-368
Selling Points
- 14 mm Thickness: Durable and robust construction for reliable performance.
- 2Gray Color: Easy to identify and integrate into various industrial settings.
- 3Rail-Mounted Compatibility: Designed for use with rail-mounted terminal blocks, enhancing connectivity.
- 4Fire Load Resistance: Meets 0.048 MJ fire load specifications, ensuring safety in high-temperature environments.
- 5Polyamide Insulation: Made with high-quality polyamide (PA66) for excellent electrical insulation properties.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 4?mm?/ 0.157?inches | Height | 32?mm?/ 1.26?inches |
Depth | 24.5?mm?/ 0.965?inches | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.048MJ | Weight | 1.6g |
Product Group | 9 (Std Chassis Mt Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 25?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332288743 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
