Product Model
267-328
Selling Points
- 1High-Quality Material: Made from chrome-nickel spring steel (CrNi) for durability.
- 2Compact Design: Modular 5- to 11-pole connector system for efficient connectivity.
- 3Flexible Compatibility: Compatible with various WAGO products, ensuring seamless integration.
- 4Robust Ratings: Rated current of 16A and rated voltage of 500V, meeting IEC/EN 60664-1 standards.
- 5Easy Installation: Snap-on type conductor support for quick and easy installation without ground contact.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Clamping units | 8 | Total number of potentials | 4 |
Number of connection types | 1 | Number of levels | 1 |
Width | 42?mm?/ 1.654?inches | Height | 15.5?mm?/ 0.61?inches |
Note (material data) | Information on material specifications can be found here | Color | white/gray |
Material group | I | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V0 | Clamping spring material | Chrome-nickel spring steel (CrNi) |
Contact material | Electrolytic copper (ECu) | Contact plating | Tin |
Fire load | 0.279MJ | Weight | 15.4g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
Temperature stability | 105°C | Product Group | 8 (Misc. Chassis Mount Blocks) |
eCl@ss 10.0 | 27-44-03-14 | eCl@ss 9.0 | 27-44-03-14 |
ETIM 9.0 | EC002560 | ETIM 8.0 | EC000458 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 500?pcs |
Packaging type | bag | Country of origin | PL |
GTIN | 4045454572211 | Customs tariff number | 39269097900 |
RoHS Compliance Status | Compliant,No Exemption | Ratings per | IEC/EN 60664-1 |
Rated voltage (III/2) | 500V | Rated surge voltage (III/2) | 4kV |
Rated current | 16A | Legend (ratings) | (III / 2) ? Overvoltage category III / Pollution degree 2 |
Connection technology | PUSH WIRE? | Solid conductor | 1.5 … 2.5?mm2 |
Strip length | 11 … 12?mm?/ 0.43 … 0.47?inches | Number of poles | 4 |
Specifications may be subject to change without notice
