Product Model
279-342
Selling Points
- 1High-Current Capability: Handles high currents up to 150A for reliable performance in demanding electrical systems.
- 2Durable Design: Constructed with robust materials ensuring long-lasting connections and resistance to environmental factors.
- 3Easy Installation: Quick and simple installation process with no need for screws, reducing setup time and effort.
- 4Versatile Applications: Suitable for a wide range of applications including industrial, automotive, and railway systems.
- 5Enhanced Safety Features: Includes protective markers and finger guards for added safety during handling and maintenance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2?mm?/ 0.079?inches | Height | 61.8?mm?/ 2.433?inches |
Depth | 25.4?mm?/ 1?inches | Note (material data) | Information on material specifications can be found here |
Color | light gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.071MJ | Weight | 2.3g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332293273 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
